Episode 3: Like what you’re done with that rabbit hole
Previously I wrote about the architectural pattern I was intending use for this adventure and I did make a start; honest.
I took initial steps to move communications into two functions, one for tfl and the other for Neo4j but…
Along came a squirrel.
Not a real one like that in the picture and really not this one 1 but a virtual one wearing a large badge of distraction that read ‘I wonder if I could get all the information needed from tfl API in fewer calls?’
Whilst quickly backfilling the justification with a dab of being efficient, I fired up PostMan2 and dived into the responses from tfl API endpoints.
Curiouser and curiouser
To recap, we had identified three tfl API endpoints for this little endeavour. One to retrieve all of the tube lines, another to give stations on a tube line and the third would provide the information to sequence stations in the correct order.
Could we reduce this to only two tfl API calls and be a bit more efficient?
Is there a tfl endpoint that can give us all of the stationss a tube line and the order in which they occur in a single response?
Looking at the response from https://api.tfl.gov.uk/Line/TUBE_LINE/Route/Sequence/inbound , we can see a glint of hope
"stations": [
{
"$type": "Tfl.Api.Presentation.Entities.MatchedStop, Tfl.Api.Presentation.Entities",
"stationId": "940GZZLUBKE",
"icsId": "1000016",
"topMostParentId": "940GZZLUBKE",
"modes": [
"bus",
"tube"
],
"stopType": "NaptanMetroStation",
"zone": "4",
tfl response with station information
There’s an array that contains station details! With the route sequences that follow later in the response, shown below, it looks like ( maybe ) we have what we need.
"orderedLineRoutes": [
{
"$type": "Tfl.Api.Presentation.Entities.OrderedRoute, Tfl.Api.Presentation.Entities",
"name": "Ealing Broadway ↔ Epping ",
"naptanIds": [
"940GZZLUEBY",
"940GZZLUWTA",
"940GZZLUNAN",
"940GZZLUEAN",
"940GZZLUWCY",
"940GZZLUSBC",
"940GZZLUHPK",
"940GZZLUNHG",
"940GZZLUQWY",
"940GZZLULGT",
"940GZZLUMBA",
"940GZZLUBND",
Station sequences
Why, sometimes I’ve believed as many as six impossible things before breakfast
After experimenting with this, I noticed that several stations were missing. It felt like getting close to the top of Everest only to discover that someone had nicked the summit. Honestly, some people will steal anything.
Not to be put off, I carried on scrolling my way through the entire response, which felt very much like doom scrolling or whatever the cool kids do, something else made its presence felt. Thankfully not the rather spicy food I had consumed the previous evening on a night out 3 but this
"stopPointSequences": [
{
"$type": "Tfl.Api.Presentation.Entities.StopPointSequence, Tfl.Api.Presentation.Entities",
"lineId": "central",
"lineName": "Central",
"direction": "inbound",
"branchId": 0,
"nextBranchIds": [
5
],
"prevBranchIds": [],
"stopPoint": [
{
"$type": "Tfl.Api.Presentation.Entities.MatchedStop, Tfl.Api.Presentation.Entities",
"stationId": "940GZZLUEPG",
"icsId": "1000076",
"topMostParentId": "940GZZLUEPG",
"modes": [
"tube"
],
"stopType": "NaptanMetroStation",
"zone": "6",
stopPoints are stations
Much checking and then some more checking, I found all of the stations for the tube line are here.
This means with one call , we can get all of the stations, their details and the sequence.
My goal of using fewer tfl calls was complete.
The best way to explain it is to do it
Nothing is that straight foward though and this new approach required a re-write of our Python code to wrangle the response to get the information we need. The Psuedo code looks like this
Get the list of tube lines from tfl api endpoint
For each tube line
Make a request to https://api.tfl.gov.uk/Line/TUBE_LINE/Route/Sequence/inbound
With the response
For each set of stop points in stopPointSequence
For each station in the set of stop points
Build up a list of station data
Send the station data for the stop point to Neo4j
For each route
For each station in the route
Build a list that links the stations together
Use the list to establish relationships between the stations in Neo4j
You can download the entire Python code that useds one less call and has the two functions for comms with tfl and Neo4j here Episode 3
There’s some basic error handling included when making network calls with tfl and Neo4j. More to do there in the future.
No, no! Sentence first—verdict afterwards.”
If you run the code you should have the entire London Tube network in Neo4j. There’s more code work to move further towards the pattern I want to use but the basics are there.
Thanks for joining me on this journey - it’s looking increasingly like it’s not going to be the fastest trip but we are dealing with the U.K public transport system and nothing happens quickly in that domain.
Until the next time, laters
-
